AUTOOL BT460 Car Battery Tester 12v 24v Battery Life Capacity Internal Resistance Testing

The AUTOOL BT460 12V/24V Car Battery Load Tester is a compact, glove-box friendly device designed to test a wide range of 12V and 24V lead-acid batteries. With advanced conductance technology, it delivers quick, accurate results for vehicles and power equipment, including regular flooded, AGM flat plate, AGM spiral, GEL, and EFB batteries. Whether you’re a professional technician or a DIY enthusiast, BT460 offers a simple, cost-effective solution for battery health assessment, cranking, charging, and maximum load testing.

AUTOOL BT460 Key Features

• Comprehensive battery testing: Battery health, cranking performance, charging status, and max load testing in a single tool.
• Broad compatibility: Tests 12V/24V lead-acid formats such as flooded, AGM flat plate, AGM spiral, GEL, and EFB.
• Safety-first design: Polarity reverse protection minimizes the risk of damage to both battery and tester.
• HD color display: Clear, easy-to-read results on a bright color screen, readable in direct sunlight.
• Multilingual support: 14 languages available for global usability.
• Generous warranty: 3-year warranty on non-user-caused damage, with prompt customer support.

What It Tests

• Evaluates actual cold-crank capacity and aging to provide a reliable maintenance baseline.
• Alerts you when a battery is aging or nearing the end of life.

Starting Test

• Measures starter motor current and voltage to confirm cranking readiness and engine reliability.

Test Modes and Operation

• Step 1: Connect the 12V/24V battery (red clips to positive, black clips to negative).
• Step 2: Battery Test — select battery type, test criteria, and range to obtain results in seconds.
• Step 3: Cranking Test — follow prompts to start the engine.
• Step 4: Charging Test — reach 2500 RPM for 5 seconds, then confirm to complete.
• Step 5: Max Load Test — enable electrical loads, start the engine, and confirm.

Detailed Test Procedures

• Battery Test: Choose battery type and test range for a quick health assessment.
• Cranking Test: Assess starter performance under load to verify starting reliability.
• Charging Test: Simulate charging conditions to evaluate charging system health.
• Max Load Test: Apply maximum electrical load while the engine is running to assess system performance.

Technical Specifications

• CCA: 30-1700
• JIS: 26A17–245H52
• DIN: 100-2200
• IEC: 100-2200
• EN: 100-2400
• SAE: 100-2400
• GB: 30-220Ah
• BCI: 100-2400
• MCA: 100-2400
• CA: 100-2400

Packaging Contents

• 1 × AUTOOL BT460 12V/24V Car Battery Load Tester
• 2 × Full copper core Kelvin clips
• 1 × User manual

Applications and Use Cases

• Automotive service centers and garages needing fast battery health checks.
• Auto parts manufacturers and service technicians requiring consistent, repeatable testing.
• DIY enthusiasts who want an affordable, portable solution for on-the-spot battery analysis.

Why Choose BT460?

• Speed and accuracy: Conductance-based testing delivers reliable results in seconds.
• Versatility: Supports multiple battery chemistries common in cars and light trucks.
• Portability: Fits in a glove box for on-the-go diagnostics.
• User-friendly: Intuitive steps and a color display for quick interpretation of results.
• Value: Competitive price point with a 3-year warranty and responsive support.
